Steel Structure Cnc H Beam Metal Cutting PLC Motor Bearing 55kW Power CNC Drilling Machine

Steel Structure Cnc H Beam Metal Cutting PLC Motor Bearing 55kW Power CNC Drilling Machine

Application:

This CNC plate punching, drilling, and marking equipment is specifically engineered for executing drilling, tapping, marking, and scoring operations on various steel types, including H-section steel, channel steel, and angle steel. It is widely utilized in steel structure industries, such as building construction, garage construction, tower fabrication, and grid structure engineering.

Specifications:

The above parameters can be adjusted and changed according to customer's specific requirements.

1. A crucial and specialized drilling solution for the building steel structure industry.
2. Capable of simultaneously drilling holes on three surfaces of H-beams and channel steels, delivering high precision and efficiency.
3. Fitted with 7 CNC axes, enabling automatic, precise feeding and positioning.
4. Capable of recognizing AUTOCAD and DSTV workpiece drawings and converting them into machining programs.

Product Features

1. The hydraulic disk marking system is available as an optional feature. The disk is positioned using a servo motor and can quickly mark up to 36 distinct characters.

2. The automatic scribing and tapping functions replace the conventional manual scribing process. Scribing tools are utilized to mark plate positions for the subsequent welding operation on H-beam flanges and webs, reducing time and labor while enhancing precision. Tapping can also be carried out on H-beam flanges and webs, significantly boosting production efficiency.

3. The clamping of the workpiece during feeding and processing, as well as the longitudinal lifting of the clamp, lateral push clamping, and the securing and release of the clamps, are all managed by the hydraulic system. This ensures the reliable operation of the equipment throughout the process.

4. The control system is comprised of a central computer and PLC, with key components sourced from prestigious international brands. It supports multiple programming methods, enabling operators to easily modify and edit various programs. Structural design data, including DXF and DSTV files generated by third-party AutoCAD or TEKLA Structures systems, can be seamlessly imported.

During sample demonstration sessions, the CNC beam plate metal drilling, marking, and shearing machine effectively showcases its processing capabilities by working with standard H-beam samples (featuring various flange widths and web thicknesses) as well as channel steel samples of different sizes. The samples presented in these demonstrations clearly highlight the machine tool’s ability to achieve precise hole positioning, smooth tapped threads, and clear marking patterns—thereby fully demonstrating its high accuracy and reliability in practical application settings.

The High-Speed CNC H-Beam Drilling, Marking, and Shearing Machine is primarily used in steel structure fabrication workshops and bridge construction projects. In steel structure workshops, it performs precise machining on H-beams used in frameworks and support systems, providing a solid foundation for the stable assembly of steel structures. In the context of bridge construction, it carries out high-precision drilling on H-beams, which not only enhances the structural integrity of the bridges but also ensures their ability to withstand long-term loads. With its high operational efficiency, the machine offers dependable support to these critical infrastructure sectors, ensuring the smooth progression of related projects.
